Pt-100 3-Wire Simplex RTD with Head Assembly & Cable Gland, 300mm Immersion Length – Reliable Temperature Measurement
Product Description:
The Pt-100 3-Wire Simplex RTD with Head Assembly & Cable Gland is a high-precision temperature sensing device designed for industrial applications requiring reliable and accurate temperature measurements. Engineered with advanced technology, this RTD (Resistance Temperature Detector) ensures precision in temperature sensing across a wide range, making it ideal for diverse applications such as HVAC systems, chemical processes, oil & gas industries, food & beverage processing, and more.
With a robust design, including a stainless steel sheath and durable head assembly, this Pt-100 RTD can withstand harsh industrial environments. Its immersion length of 300mm ensures accurate readings even in deep or hard-to-reach locations, and the 3-wire configuration provides superior accuracy by compensating for lead wire resistance.
Key Features:
- Pt-100 3-Wire Simplex RTD: This RTD is built with a 3-wire configuration, which helps reduce error due to lead resistance, providing more accurate temperature measurements.
- Wide Temperature Range: The RTD can measure temperatures from -50°C to 400°C, making it suitable for various applications, from low-temperature to high-temperature environments.
- Head Assembly & Cable Gland: The unit is complete with a sturdy head assembly and a 3/4″ cable gland, ensuring secure and reliable electrical connections in industrial setups.
- Stainless Steel Sheath: The sensor features a 16mm OD stainless steel sheath below the head, offering corrosion resistance and durability, even in aggressive environments.
- Immersion Length of 300mm: With an immersion length of 300mm, this RTD can be used in applications requiring deep insertion, ensuring precise temperature readings from the medium being monitored.
- Versatile Applications: This RTD is suitable for a range of industries including process control, petrochemical, manufacturing, power generation, and more.
- Superior Stability & Accuracy: Pt-100 sensors are known for their exceptional stability and long-term reliability, providing accurate readings over time.
Applications:
- HVAC Systems: Monitoring and controlling temperature in heating, ventilation, and air conditioning systems for optimal performance.
- Process Control: Used in industries where precise temperature regulation is crucial, such as chemical manufacturing, food processing, and pharmaceuticals.
- Oil & Gas: Monitoring temperature in pipelines, storage tanks, and other critical areas to ensure safe and efficient operations.
- Power Plants: Used for monitoring temperature in power generation systems to optimize performance and ensure safety.
- Water Treatment: Used in water heating and cooling systems to maintain the desired temperature for effective processing.
Why Choose the Pt-100 3-Wire Simplex RTD?
The Pt-100 3-Wire Simplex RTD offers industry-leading accuracy and stability for critical temperature measurements. Whether you need reliable temperature data for maintaining consistent process conditions, ensuring safety in high-risk environments, or optimizing energy usage, this RTD sensor meets the stringent demands of industrial applications.
- Accuracy and Precision: The 3-wire configuration significantly enhances measurement accuracy by compensating for errors due to lead wire resistance. This ensures you get reliable readings even in long-distance installations.
- Durability in Harsh Environments: With a stainless steel sheath and rugged head assembly, this RTD is built to withstand tough industrial environments. The sensor is resistant to corrosion, high temperatures, and mechanical wear, making it a dependable choice for long-term use.
- Wide Range of Applications: The Pt-100 3-Wire Simplex RTD is versatile enough for use in a wide array of industries, from power plants to HVAC systems. Its broad temperature range (-50°C to 400°C) allows it to function in both extreme cold and hot environments without compromising accuracy.
- Quick and Easy Installation: The inclusion of a 3/4″ cable gland and head assembly ensures quick and secure electrical connections. The RTD is designed for easy integration into existing systems, reducing installation time and labor costs.
Maintenance and Care:
To ensure the long-term performance of the Pt-100 3-Wire Simplex RTD, regular maintenance checks should be conducted, especially in high-temperature or corrosive environments. Check the cable gland and head assembly for any signs of wear or damage and ensure that the RTD is securely mounted in its application environment.
When cleaning the RTD, use a non-corrosive solution and avoid contact with abrasive materials to preserve the integrity of the stainless steel sheath.
Why Pt-100 Technology?
The Pt-100 sensor is one of the most widely used temperature sensors in industrial applications due to its exceptional accuracy, stability, and repeatability. It operates on the principle that the electrical resistance of platinum changes with temperature. The “100” in Pt-100 refers to the fact that the sensor has a resistance of 100 ohms at 0°C.
Pt-100 sensors are more stable and provide more accurate readings compared to thermocouples, especially over longer periods of time. Their precision makes them the preferred choice for industries where accurate temperature measurement is critical for safety and efficiency.
Conclusion:
For industries that demand precise and stable temperature measurements, the Pt-100 3-Wire Simplex RTD with Head Assembly & Cable Gland is the ideal solution. With its durable construction, wide temperature range, and easy installation, this RTD provides unmatched performance and reliability. Whether you’re monitoring HVAC systems, chemical processes, or other industrial applications, you can trust this RTD to deliver accurate and consistent temperature readings every time.
Upgrade your temperature monitoring capabilities with the Pt-100 3-Wire Simplex RTD today and ensure the highest levels of accuracy and reliability for your operations.
Japsin Instrumentation – Since 1974
